KBS Generation Junior Graphite Iron Shaft Parallel (.370)
KBS Generation Junior Graphite Iron Shaft Parallel (.370)
KBS GENERATION
Graphite Iron Shaft
Purpose-built for younger golfers with developing speed, GENERATION helps create easier launch, added spin and dependable accuracy in an ultralight graphite iron platform.
Launch it higher. Keep it in the air. Build confidence.
GENERATION is based on the E.I. curve of KBS MAX and adapted for younger players. Its lightweight graphite construction is engineered to help slower developing swings create useful trajectory, spin and accuracy.
Easier Launch
A high-launch profile helps young players get iron shots airborne without fighting an overly heavy or demanding shaft.
Helpful Spin
High-spin performance supports carry and stopping ability for golfers who do not yet generate adult-level speed.
Lightweight Control
The 40g and 50g options reduce shaft mass while maintaining a purpose-built iron profile designed around developing players.
Designed around the needs of developing swings
Trajectory
High
Helps launch iron shots into a playable flight window.
Spin
High
Supports carry and landing control at lower speeds.
Shaft Weight
Ultralight
40g and 50g choices for fitting smaller players.
Young players—not simply shorter clubs
A well-built junior set should account for the golfer’s hand size, strength, measured speed and posture. KBS lists this family for younger players with lower swing speeds and provides fitting guidance of 50 mph or less, then fit to hand size.
- Needs significantly less shaft weight than an adult iron build
- Benefits from added launch and spin
- Uses iron heads with .370 parallel hosels
- Will be assembled and trimmed specifically for the player
Weight and length should grow with the golfer
Junior equipment should make solid contact easier—not force the player to adapt to a shaft that is too long, heavy or stiff. The 40g and 50g options give a fitter two starting points for matching the build to the golfer.
- Measure the player before choosing finished club length
- Check grip size and total club weight along with shaft weight
- Reassess the fit as height, strength and speed change
- Use the correct weight-specific trimming row for every club
Two lightweight fitting options
KBS specifies both options for lower-speed younger players and directs fitters to consider hand size. The 50g model uses an additional 1/2-inch of tip trim at every listed club compared with the 40g model.
GENERATION 40
KBS frequency designation 1.5. The lightest option and the starting point for the smallest or least powerful players when confirmed through fitting.
GENERATION 50
KBS frequency designation 2.5. Adds shaft weight and uses a firmer standard trimming progression for players who need that step.
KBS GENERATION graphite iron details
| Weight | KBS Fitting Guidance | Frequency | Tip | Raw Length | Launch | Spin |
|---|---|---|---|---|---|---|
| 40g | 50 mph or less; fit to hand size | 1.5 | .370" parallel | 36"/38" range by model | High | High |
| 50g | 50 mph or less; fit to hand size | 2.5 | .370" parallel | 36"/38" range by model | High | High |
KBS publishes 36-inch and 38-inch raw lengths across the two models. Confirm the exact stocked raw length for the selected weight before planning a build.
Weight-specific .370 tip trimming
Remove the listed amount from the tip end for the intended club, install the shaft, then butt trim to the player’s final fitted length. Measurements below reproduce KBS’s current GENERATION graphite-iron chart.
| Target Club | 40g Tip Trim | 50g Tip Trim | Then |
|---|---|---|---|
| 4-Iron | 0" | 1/2" | Butt trim to fitted length |
| 5-Iron | 1/2" | 1" | Butt trim to fitted length |
| 6-Iron | 1" | 1 1/2" | Butt trim to fitted length |
| 7-Iron | 1 1/2" | 2" | Butt trim to fitted length |
| 8-Iron | 2" | 2 1/2" | Butt trim to fitted length |
| 9-Iron / PW | 2 1/2" | 3" | Butt trim to fitted length |
Cutting changes shaft performance. Verify the selected weight, club and current KBS instructions before trimming. Any club not shown in the chart requires guidance from KBS or a qualified builder.
One blank for each club being built
This is a single-length parallel-tip shaft sold individually. Order one shaft per iron, then trim each blank using the correct weight and target-club row.
Example: a 4–PW set uses seven shafts.
These are not discrete .355 taper shafts. Every .370 blank must be tip trimmed for its intended club and butt trimmed to the player’s fitted length. Confirm hosel diameter and available parallel-tip insertion depth before cutting.
- Confirm the head accepts a .370 parallel shaft
- Correctly identify the 40g or 50g model
- Tip trim first; butt trim afterward
- Professional junior fitting and assembly are strongly recommended
Before you order
Is this an adult graphite iron shaft?
GENERATION is specifically designed for younger players with lower swing speeds. It should be selected through an age-appropriate fitting rather than treated as a lightweight adult shaft by default.
Is this listing .370 parallel tip?
Yes. This product is the .370-inch parallel-tip version. It requires club-specific tip trimming and final butt trimming during assembly.
Which weights does KBS currently offer?
KBS’s current GENERATION graphite-iron page lists 40g and 50g. Those weights use different frequency designations and different standard tip-trimming rows.
Should I choose solely by the golfer’s age?
No. Height, hand size, strength, measured speed, posture and athletic development can vary widely among golfers of the same age. Fit the player rather than relying on age alone.
Are the shafts sold individually?
Yes. One shaft is needed for every club being assembled. For example, a 4–PW set requires seven shafts.
Can I use the same trimming instructions for both weights?
No. The 50g model uses 1/2 inch more tip trim than the 40g model at each club position in the current KBS chart. Confirm the shaft weight before cutting.
Can I use this in a .355 taper hosel?
Not as a direct fit. This listing is intended for .370 parallel hosels. Any nonstandard installation solution should be evaluated and completed by a qualified club builder.
Build junior clubs around the golfer—not the calendar
Grater Golf can help confirm the appropriate shaft weight, .370 hosel compatibility, set quantity, grip size, trimming and finished length before you order.
Contact Grater GolfShaft only. Clubhead, grip, ferrule, assembly, trimming and installation are not included unless specifically selected. Product appearance and availability may vary. Verify the selected model and all build specifications before cutting or installation.
