Stable Delivery
A stable graphite structure supports confident hybrid swings, face control and more repeatable contact.
KBS Tour Graphite Hybrid Prototype Shaft
Regular price
$135.00
Sale price
$135.00
Regular price
Unit price
Sale
Estimated Handling Time
1-2 Days, Free Shipping
Carrier transit time begins after your order ships.
KBS Tour Graphite Hybrid Prototype Shaft
Overview
Shipping and Returns
Performance and stability
KBS Tour Graphite Hybrid Prototype Shaft
Inspired by the KBS Tour steel shaft, the Tour Graphite Hybrid Prototype brings signature KBS feel to a stable graphite hybrid platform. Its broad 65g–105g matrix is designed for confident, aggressive hybrid shots and a cohesive transition into KBS iron and wedge shafts.
65g–105g
17 Configurations
42" Raw Length
.370" Parallel Tip
KBS Tour-Inspired FeelGraphite hybrid performance informed by the KBS Tour family
Five Weight Classes17 available weight and flex combinations
Grater Golf SupportHelp with fitting, compatibility, trimming and installation
Tour-Inspired Stability for Hybrid Clubs
The Tour Graphite Hybrid Prototype is engineered for performance and stability throughout the shaft, giving players the confidence to make an aggressive swing while maintaining the connected feel associated with KBS.
Signature KBS Feel
KBS translated the feel concept of its Tour steel family into a purpose-built graphite hybrid platform.
Set-Wide Continuity
Designed to create a smoother performance transition from the hybrid into KBS iron and wedge shafts.
A serious hybrid fitting matrix
Dial In Weight and Flex Separately
Unlike a one-weight-per-flex system, the Tour Graphite Hybrid Prototype offers several flexes across multiple weight classes. That gives fitters more freedom to tune shaft mass, loading feel and stability for the player, hybrid loft and intended role in the set.
- Graphite design inspired by the KBS Tour steel shaft
- Stable profile for confident hybrid swings
- Five weight classes from 65g through 105g
- Regular, Regular+, Stiff, Stiff+ and X-Stiff options
- 17 available weight and flex combinations
- Single-length 42-inch raw shaft
- .370-inch parallel hybrid tip
Tour Prototype fitting range
From Lighter Speed to Heavyweight Stability
Choose weight and flex together. Shaft mass affects timing, total club weight and impact feel, while flex changes how the shaft loads and releases. The best match also depends on tempo, transition, hybrid length, head weight and desired ball flight.
65–105gFive weight classes
R–XAvailable flex range
42"Raw shaft length
.370"Parallel hybrid tip
Choose Your Weight and Available Flex
Each weight has a specific KBS flex menu. Use the exact matrix below when selecting your build.
Regular • Stiff • X-Stiff
Regular • Stiff • X-Stiff
Regular • Regular+ • Stiff • Stiff+ • X-Stiff
Stiff • Stiff+ • X-Stiff
Stiff • Stiff+ • X-Stiff
Important: Regular+ is available only at 85g. Stiff+ is
available at 85g, 95g and 105g. The standard Regular option stops at 85g.
Confirm both dropdown selections before adding the shaft to your cart.
Technical and Frequency Reference
KBS’s builder chart lists the internal frequency references corresponding to each available flex.
| Weight | Available Flexes | KBS Frequency Reference | Raw Length | Tip Diameter |
|---|---|---|---|---|
| 65g | Regular, Stiff, X-Stiff | 3.0, 4.0, 5.0 | 42" | .370" |
| 75g | Regular, Stiff, X-Stiff | 4.0, 5.0, 6.0 | 42" | .370" |
| 85g | Regular, Regular+, Stiff, Stiff+, X-Stiff | 5.0, 5.5, 6.0, 6.5, 7.0 | 42" | .370" |
| 95g | Stiff, Stiff+, X-Stiff | 6.25, 6.75, 7.25 | 42" | .370" |
| 105g | Stiff, Stiff+, X-Stiff | 6.5, 7.0, 7.5 | 42" | .370" |
The frequency numbers above are KBS fitting and build references—not a
universal flex scale or guaranteed finished-club CPM measurement. Compare
them within the Tour Prototype family and confirm the complete build with a fitter.
Where Should You Start?
Use shaft mass to frame the fit, then test the flex that produces the best delivery, strike and ball flight.
65g–75g
Consider the lighter end when preserving speed or reducing total club weight matters, while retaining the Tour Prototype stability concept.
85g
The center of the range and the only weight offering all five flex choices—useful when fine-tuning feel without changing shaft mass.
95g–105g
Consider the heavier end when added shaft mass and a substantial feel help the hybrid blend into a heavier iron setup.
KBS Hybrid Trimming Guide
This 42-inch single-length parallel shaft must be tip and butt trimmed for the intended hybrid.
0"–2"Progressive tip trimming by hybrid number
Trim for the Hybrid Being Built
KBS specifies no tip trim for a 2-hybrid, then adds one-half inch for each step through the 6-hybrid. After the correct tip trim, butt trim the shaft to the required finished playing length.
KBS bases this schedule on the longest hybrid in the OEM series. Confirm the hybrid number, head or adapter, insertion depth and desired finished specifications before cutting.
| Hybrid | Standard Tip Trim | Next Step |
|---|---|---|
| 2-Hybrid | 0" | Butt trim to finished playing length |
| 3-Hybrid | 0.5" | Butt trim to finished playing length |
| 4-Hybrid | 1" | Butt trim to finished playing length |
| 5-Hybrid | 1.5" | Butt trim to finished playing length |
| 6-Hybrid | 2" | Butt trim to finished playing length |
Professional installation recommended. Tip trimming a
graphite shaft is permanent and changes its playing characteristics. A
qualified builder should confirm the head, hosel or adapter, insertion
depth, playing length and swing-weight target before cutting.
Hybrid Compatibility
The .370-inch tip specification must match the head or adapter being used.
The Tour Graphite Hybrid Prototype uses a .370-inch parallel
tip. It is intended for compatible hybrid heads or adapters made
for a .370-inch shaft. It is not a direct fit for .355-inch taper-tip
hybrid hosels or .335-inch wood adapters. Requirements vary by brand and
model, so confirm compatibility before ordering or cutting the shaft.
Frequently Asked Questions
Who is the Tour Graphite Hybrid Prototype designed for?
It is designed for players seeking KBS Tour-inspired feel, graphite construction and stable hybrid performance. Its 17 configurations allow a fitter to tune weight and flex for a wide range of stronger or more aggressive deliveries.
Can I choose every flex in every weight?
No. The exact flex menu changes by weight. The 85g model offers all five flexes; 65g, 75g, 95g and 105g each have three available flexes.
How is this different from KBS PGH?
The Tour Prototype is KBS Tour-inspired and begins at 65g, with multiple flexes available in several weights. PGH extends the Players Graphite platform down to 45g and emphasizes easier launch across a broader player range.
Will this shaft fit my hybrid?
It fits compatible hybrid heads or adapters designed for a .370-inch parallel shaft. Confirm your exact club model and hosel or adapter specification before ordering.
Does it require both tip and butt trimming?
Yes. It is a 42-inch single-length parallel shaft. Tip trim it for the intended hybrid number, then butt trim it to the desired finished playing length.
What is included?
This listing is for one uncut KBS Tour Graphite Hybrid Prototype shaft in the selected weight and flex. A clubhead, grip, adapter, ferrule, trimming and installation are not included unless specifically shown in the selected option.
Need Help Choosing Your Tour Prototype?
Tell Grater Golf your hybrid model and loft, current shaft, iron-shaft weight, playing length, typical ball flight and what you want to improve. We’ll help you confirm weight, flex, tip compatibility and build requirements before you order.
Contact Grater GolfShaft only. Clubhead, grip, adapter, ferrule, trimming and installation are not included unless specifically selected. Published weight names are KBS model categories rather than guaranteed finished weights. Product appearance and availability can vary.
