Graphite Design Tour AD DI Wood Shaft
Graphite Design Tour AD DI Wood Shaft
Graphite Design Tour AD
Tour AD DI Wood Shaft
Create a “Deep Impact” with the Graphite Design Tour AD DI. Designed and manufactured in Japan, this premium wood shaft combines a smooth-loading midsection with a stable tip to promote greater speed, exceptional feel and controlled performance.
Mid-High to High Launch
Engineered to help golfers produce an elevated, powerful trajectory.
Low Spin
A firm tip section helps control spin and maintain stability through impact.
Smooth Loading
The softer midsection helps the golfer load the shaft while preserving control.
Made in Japan
Manufactured at Graphite Design’s factory headquarters in Japan.
Performance Profile
The Tour AD DI uses a medium butt section, medium midsection and stiff tip section. Its responsive midsection helps the golfer properly load the shaft, while the stable tip supports control through impact.
Tour AD DI Technology
DI Technology
The Tour AD DI was Graphite Design’s first shaft to incorporate Toray Composites’ NANOALLOY material technology in the tip section. This construction increases stability without sacrificing the responsive feel golfers expect from the Tour AD family.
Premium Carbon Construction
Premium 50-ton, high-modulus aerospace-quality carbon fiber is combined with Graphite Design’s proprietary Material Stiffness Integration design philosophy to balance feel, stability and performance.
Color Availability
Select models are available in either the signature orange finish with white bands and green rings or a black finish with white bands and silver rings.
- Orange or black: DI-5 R2, R1 and S; DI-6 SR, S and X; DI-7 S and X; DI-8 S and X
- Orange only: DI-5 X, DI-6 TX, DI-7 TX, DI-8 TX and DI-9 X
Who Is the Tour AD DI For?
The Tour AD DI is a strong option for golfers seeking a smooth-loading premium shaft that promotes an elevated trajectory without excessive spin.
- Golfers seeking mid-high to high launch
- Players who want low-spin performance
- Golfers who prefer a responsive midsection and stable tip
- Players looking for a wide selection of weights and flexes
- Golfers who value a smooth, controlled feel through impact
General Flex Selection Guide
Use driver swing speed as a starting point. Tempo, transition, release pattern and desired ball flight should also be considered during fitting.
| Driver Swing Speed | Suggested Flex |
|---|---|
| 71–85 mph | R2 / Lite-Senior |
| 86–95 mph | R1 / Regular |
| 92–98 mph | SR / Stiff Regular |
| 96–105 mph | S / Stiff |
| 105+ mph | X / X-Stiff |
| 110+ mph | TX / Tour X-Stiff |
Tour AD DI Specifications
| Model | Color | Flex | Length | Weight | Tip | Parallel Tip | Butt | Torque | Kick Point | Launch | Spin |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DI-5 R2 | Orange or Black | Lite/Senior | 46" | 53.5g | .335" | 3.0" | .595" | 4.7° | Low/Mid | High | Low |
| DI-5 R1 | Orange or Black | Regular | 46" | 55g | .335" | 3.0" | .596" | 4.7° | Low/Mid | High | Low |
| DI-5 S | Orange or Black | Stiff | 46" | 56.5g | .335" | 3.0" | .598" | 4.6° | Low/Mid | High | Low |
| DI-5 X | Orange | X-Stiff | 46" | 60.5g | .335" | 3.0" | .602" | 4.6° | Low/Mid | High | Low |
| DI-6 SR | Orange or Black | Stiff Regular | 46" | 63.5g | .335" | 3.0" | .598" | 3.4° | Low/Mid | High | Low |
| DI-6 S | Orange or Black | Stiff | 46" | 65g | .335" | 3.0" | .600" | 3.3° | Low/Mid | High | Low |
| DI-6 X | Orange or Black | X-Stiff | 46" | 66.5g | .335" | 3.0" | .604" | 3.3° | Low/Mid | High | Low |
| DI-6 TX | Orange | Tour X-Stiff | 46" | 68.5g | .335" | 3.0" | .602" | 3.3° | Low/Mid | High | Low |
| DI-7 S | Orange or Black | Stiff | 46" | 73.5g | .335" | 3.0" | .600" | 3.2° | Mid | Mid/High | Low |
| DI-7 X | Orange or Black | X-Stiff | 46" | 75g | .335" | 3.0" | .602" | 3.1° | Mid | Mid/High | Low |
| DI-7 TX | Orange | Tour X-Stiff | 46" | 76.5g | .335" | 3.0" | .604" | 3.1° | Mid | Mid/High | Low |
| DI-8 S | Orange or Black | Stiff | 46" | 83.5g | .335" | 3.0" | .604" | 3.0° | Mid | Mid | Low |
| DI-8 X | Orange or Black | X-Stiff | 46" | 84.5g | .335" | 3.0" | .606" | 2.9° | Mid | Mid | Low |
| DI-8 TX | Orange | Tour X-Stiff | 46" | 86g | .335" | 3.0" | .608" | 2.9° | Mid | Mid | Low |
| DI-9 X | Orange | X-Stiff | 46" | 97g | .335" | 3.0" | .610" | 2.6° | Mid | Mid | Low |
Standard-Bore Tip-Trimming Guide
| Driver | 3-Wood | 5-Wood | 7-Wood | 9-Wood |
|---|---|---|---|---|
| 0" | 0.5" | 1.0" | 1.0" | 1.0" |
Always leave at least 0.5" of the parallel tip section above the hosel. Trimming requirements may change with nonstandard bore depths, adapters or individual fitting specifications.
Professional Installation Recommended
Shaft selection, tipping, adapter installation and finished playing length can affect launch, spin, feel and effective flex. Grater Golf recommends professional fitting and installation to ensure the shaft is properly configured for your swing and clubhead.
Shaft only unless otherwise specified. Clubhead, adapter and grip are not included unless selected through an available custom-build option. Product appearance may vary by model and color selection.
